Zone 3 Runs With All Others: Wiring Cross or Pump Start Wire Fault
Zone 3 On During Every Zone; Valve Replaced, Wire Disconnected at Controller, Still Runs Fault in field wiring: hot wires touching, or Zone 3 wire crossed with pump start/master valve wire (which energizes whenever any z
Irritrol KwikDial Two Solenoids Per Station Fail After 3 Years: Voltage Drop Under Load
Stations 2 and 3 Each Drive Two Solenoids; Work Individually, Fail Combined After 3 years, combined solenoids dont actuate. Single works. Cause Insufficient voltage at solenoids when two wired in parallel (wire gauge to
Toro DDC Pump Stays On After Cycle: Unused Zones Have Run Times Programmed
Two Zones Programmed, But Pump Runs After Both Finish Check all zone slots (1–6+). If Zone 3 has 10 min but no valve, controller still activates it and the pump relay. Fix Zero out run times for all unused zones.
Irritrol RD-900 Flashing LCD, Manual Start Shows OFF: Shorted Valve or Wire
Manual Button Flashes Run Time Then Shows OFF Short in valve solenoid or its wiring. Find Faulty Zone Test zones manually one by one. Zone that triggers OFF has the fault. All zones trigger → wiring issue (common short
Irritrol RD-600 Won't Run After Battery Swap: Need More Info to Diagnose
Battery Doesnt Run System; Many Possible Causes Need to know: Is timer plugged in? Weather sensor? Pump/master valve? Recent yard/home work? Auto and manual both fail? Any irrigation work done? No Specific Answer Withou
Enki Controller "NO AC" on Manual Start: Solenoid Short or Controller Fault
NO AC Means Power Loss When Valve Activates Disconnect wire from terminal #1. Try manual start Zone 1. NO AC gone → Zone 1 solenoid or wire shorting controller. NO AC persists → controller fault. Also Try Full power c
Richdel 446PR Dead After 1990 Install: Replace with Irritrol Rain Dial
Controller Dark, Power OK, Battery Replaced, No Life Surprised it lasted this long. Not made anymore. Replace with Irritrol Rain Dial — well-built, easy programming, long life.
Irritrol RD600 Pump Start Signal Every 60 Sec: Test Controller Output Continuity
Pump Should Get Continuous Signal, But Gets Pulsed; Relay Clicks, Pump Doesnt Start Disconnect pump start wire at controller. Run zone, measure voltage at terminal continuously. Continuous 22–26V → controller OK; fault
Hunter SRC-600i No Auto or Manual Run: Likely Controller Failure
Unplugged Previously, Now Dead; No Fuse on Hybrid Model Check terminal outputs to rule out common wire or master valve issue. Verify pump/well works if isolated. Most Likely Timer needs replacement. Document wire-to-ter
Orbit Timer Pump Start Fails: Voltage Drops Under Load, Controller or Wiring Fault
24V at Pump Terminal No Load, Drops to 1V with Relay Connected Relay tested OK. Other terminals work. Pump terminal fails under load. Diagnosis Check voltage at relay end of wires. If 24V there → relay fault. If 1V → wi
Century 3" Hydraulic Valves Leak: Rebuild with Diaphragm and Solenoid
8-Station Hydraulic System, Some Sprinklers Stay On Rebuild valves: new diaphragm and possibly solenoid. See irrigationtutorials.com for guidance.
Rain Jet RJC-66 No Operation: Systematic Checks or Replace Controller
15+ Year Old System, Nothing Works Check: 1) Water on, 2) Controller output 24V, 3) Wires intact, 4) Valves work. Likely Controller Failed Replace with Irritrol Rain Dial — available at irrigation supply stores.
Hunter Pro-C Backyard Zones Dead After Aeration: Likely Wire Cut
Front/Side Zones Work, Backyard Zones 6,7,8 Dead; Aeration Recently Done Wire to backyard likely cut during aeration. All three zones share a wire run. Fix Hire pro with wire locator to trace and find break. Repair or r
Hydro Rain HR 6100 Only Runs Station 1: Test by Disconnecting Station 2 Wire
Manual Start Runs Station 1 for 1 Min, Then Stops Disconnect wire from terminal #2. Run manual cycle. Display still stops at Station 1 → controller bad. Display advances → Station 2 solenoid or wiring fault. Replaceme
Rain Bird RC-7Bi with K-Rain Indexing Valve: Zones Change on Manual Advance
4 Output Wires from Timer → 2 Wires to Indexing Valve Indexing valve (K-Rain 4000) rotates mechanically with water pressure. Each pressure cycle advances to next outlet. Timer cant control individual zones. Solution Ins
Hardie RD-600 Shows "7" and Freezes: Power Surge Reset Fix
Your Hardie RD-600 displays 7 and buttons dont respond. The manual doesnt list error code 7. Heres the deal: this controller doesnt use error codes. The 7 is likely a corrupted display from a power surge. Hard Reset Pro
Sprinkler Head Runs Non-Stop? The Valve Diaphragm Is Stuck Open
You added a sprinkler head, capped the others on that zone. The new head works when the timer runs—but wont shut off when the zone closes. Even turning off the timer doesnt stop it. Only closing the main water supply sto
Hunter X-Core to Orbit Iris Timer Swap: Direct Wire Compatibility
Timers Interchangeable Across Brands Yes, swap Hunter for Orbit. Critical: label each field wire as removed (1, 2, 3… and C/common), reconnect to same terminals on new controller.
Sprinkler Heads Won't Pop Up: Valve, Head Count, or Supply Issue
Heads Gurgle, Dont Rise; Manual Push Fixes Temporarily Three common causes: Valve not opening fully → old diaphragm, replace. Too many heads on zone → add valve, reduce heads. Main supply valve not fully open → check an
Irritrol MC-6 "Error 2": Internal Hardware Fault
Screen Shows Error 2, Unresponsive Internal hardware problem. Power off 5 minutes, restart. If Persists Controller needs repair or replacement.
